🖼️ Working with Images¶
How to include and work with images in documentation
Overview¶
Images are an essential component of documentation, serving to illustrate concepts, display screenshots, and visualize data. Introligo supports images through markdown includes, simplifying the integration of visual content into documentation.
Image Organization¶
Directory Structure¶
For Sphinx documentation, images should be placed in the _static directory:
docs/
├── _static/
│ └── images/ # Images for documentation
│ ├── logo.png
│ ├── screenshot1.png
│ └── diagram.svg
├── composition/
│ └── markdown/
│ └── md_tutorial/
│ └── working_with_images.md
└── generated/ # Generated RST files
└── user_guide/
└── markdown_includes/
└── working_with_images.rst
Rationale for using `_static`:
The _static directory is Sphinx’s standard location for static assets including images, CSS, and JavaScript. Files in _static are automatically copied to the build output and remain accessible via the _static/ path in generated documentation.
Including Images in Markdown¶
Basic Image Syntax¶
Use standard markdown image syntax with paths to _static/images:
Image with Title¶
Understanding Image Paths¶
Important: Paths must be relative to where the generated RST files will be located, not relative to the markdown source file.
For Introligo with default settings: - Markdown files are in: docs/composition/markdown/md_tutorial/ - Generated RST files end up in: docs/generated/user_guide/markdown_includes/ - Images should be in: docs/_static/images/ - Therefore, use path: ../../../_static/images/filename.png (go up 3 levels, then into _static/images)
# Standard path for images in Introligo documentation
Image Examples¶
Example 1: Simple Image¶
The first example demonstrates basic image inclusion:
This image demonstrates a basic image inclusion. The syntax used:
Note: The path ../../../_static/images/ works because: - Generated RST files are in docs/generated/user_guide/markdown_includes/ - Go up 3 levels (../../../) to reach docs/ - Then access _static/images/ directory where images are stored
Example 2: Image with Caption¶
The second example demonstrates the use of descriptive alt text:
This image includes more descriptive alt text for better accessibility:
Best Practices¶
1. Use Descriptive Alt Text¶
Always provide meaningful alt text for accessibility:
Recommended:
Not recommended:
2. Optimize Image Sizes¶
PNG: Good for screenshots, diagrams, logos
JPG/JPEG: Good for photos, complex images
SVG: Best for diagrams, icons (scalable)
GIF: For simple animations
Recommended maximum dimensions: - Screenshots: 1920px width maximum - Diagrams: 1200px width maximum - Icons/logos: 512px maximum
3. Consistent Naming Convention¶
Use clear, descriptive filenames:
Recommended:
- user-login-flow.png
- architecture-diagram.svg
- installation-screenshot-01.png
Not recommended:
- img1.png
- screenshot.png
- pic.jpg
4. Image Directory Organization¶
For large projects, organize by category in _static/images:
docs/_static/images/
├── screenshots/
│ ├── installation/
│ │ ├── step1.png
│ │ └── step2.png
│ └── usage/
│ └── interface.png
├── diagrams/
│ ├── architecture.svg
│ └── workflow.svg
└── logos/
└── project-logo.png
Reference with subdirectories (adjust ../../../ based on your RST depth):
Advanced Techniques¶
Responsive Images¶
While markdown doesn’t support responsive images directly, you can use RST directives in your markdown when needed. Introligo converts markdown to RST, so you can mix formats:
This is markdown text.
.. figure:: ../../../_static/images/diagram.png
:width: 80%
:align: center
:alt: System Architecture
System Architecture Diagram
Image Alignment¶
For centered images in RST (mixed with markdown):
.. image:: ../../../_static/images/logo.png
:align: center
:width: 300px
Multiple Images in a Row¶
Using RST table syntax for side-by-side images (using your actual images):
.. list-table::
:widths: 50 50
* - .. figure:: ../../../_static/images/image1.png
:width: 100%
Caption for Image 1
- .. figure:: ../../../_static/images/image2.png
:width: 100%
Caption for Image 2
Image Checklist¶
Before adding images to documentation:
- Image is optimized for web (reasonable file size)
- Filename is descriptive and uses kebab-case
- Alt text is meaningful and descriptive
- Image is in the
_static/imagesdirectory or subdirectory - Relative path is correct from generated RST location
- Image format is appropriate (PNG/JPG/SVG)
- Image is version controlled (committed to git)
- Copyright/license is clear (if not your own image)
Example Configuration¶
The following demonstrates how to include this tutorial with images in introligo_config.yaml:
modules:
markdown_images:
parent: "markdown_includes"
title: "🖼️ Working with Images"
description: "How to include and work with images in documentation"
markdown_includes: "markdown/md_tutorial/working_with_images.md"
Additional Recommendations¶
Version Control for Images¶
Always commit images to your repository so the documentation builds correctly for all team members:
git add docs/_static/images/new-image.png
git commit -m "docs: Add new diagram to image tutorial"
Preview Before Committing¶
Build and preview documentation locally before committing changes:
python -m introligo docs/composition/introligo_config.yaml -o docs
cd docs && sphinx-build -b html . _build/html
Dark Mode Considerations¶
For documentation supporting dark mode themes, consider providing alternative images or using SVGs with appropriate colors.
Accessibility Considerations¶
Proper alt text provides multiple benefits: - Assists screen reader users in understanding content - Provides fallback when images fail to load - Improves search engine indexing of documentation
